Silverz · 01-30-2019, 06:42 PM

Can someone help me locate the control arm torque specs?

For all three locations on the control arm.

Ultramaroon · 01-30-2019, 06:57 PM

Link to the service manuals in my sig line.

Beachin86 · 01-30-2019, 06:59 PM

I'd go by what you can find in the service manuals that Ultramaroon posted. I found these from the coilover install video from ft86speedfactory:

Rear Strut to LCA: 59 ft/lbs
Rear Strut to Chassis: 22 ft/lbs
LCA to Chassis: 59 ft/lbs
Endlink to LCA: 28 ft/lbs

Link to vid: [ame]https://www.youtube.com/watch?v=rDwxf017Kbw&t=227s[/ame]

Leonardo · 01-30-2019, 07:02 PM

Quote:

Originally Posted by Ultramaroon

Link to the service manuals in my sig line.

Silverz · 01-30-2019, 07:32 PM

Quote:

Originally Posted by Ultramaroon

Link to the service manuals in my sig line.

Thanks. What I needed.
