FR-S Matt · 04-18-2013, 04:26 PM

Quote:

Originally Posted by JDLAutoDesign

Sending an UEL today to @Simmons. He will dyno/tune for gas and E85

Look forward to the results!

kask2_6.0 · 04-18-2013, 08:17 PM

Quote:

Originally Posted by JDLAutoDesign

Ok we will be doing the first 10 at $799 on the UEL. PM if you want to hop on it!

PM'd

JDLAutoDesign · 04-18-2013, 10:56 PM

A few teaser shots as Jesse finishes welding up the header

OmarGC · 04-18-2013, 10:58 PM

Nice welds

JDLAutoDesign · 04-18-2013, 11:42 PM

One more teaser before we close for the night. WIll have finalized product shots tomorrow

JoeBoxer · 04-19-2013, 12:32 AM

Wow that looks great and price is right for sure. Don't forget the warranty too.

ft_sjo · 04-19-2013, 01:18 AM

Could you show us the insides of one of those expansion joints please?

Jesse@JDLAutodesign · 04-19-2013, 01:40 AM

Quote:

Originally Posted by ft_sjo

Could you show us the insides of one of those expansion joints please?

Yes we will take some tomo. We will also have detailed shots of the collector inside as well as pictures to show the backpurging on the inside of the tubes.

thomsontrang · 04-19-2013, 02:39 AM

Quote:

Originally Posted by JDLAutoDesign

Ok we will be doing the first 10 at $799 on the UEL. PM if you want to hop on it!

You have PM. Also it includes gaskets right?

Captain Snooze · 04-19-2013, 06:53 AM

I do not know the reasons behind the decision to have the single exhaust exiting at such an angle but might it be possible to add a bend so it exits straight out the back? (Pardon the dodgy paint picture).

xxscaxx · 04-19-2013, 01:08 PM

Quote:

Originally Posted by JDLAutoDesign

One more teaser before we close for the night. WIll have finalized product shots tomorrow

Khánh · 04-19-2013, 04:37 PM

Quote:

Originally Posted by Captain Snooze

I do not know the reasons behind the decision to have the single exhaust exiting at such an angle but might it be possible to add a bend so it exits straight out the back? (Pardon the dodgy paint picture).

i'm guessing to eliminate the bends as much as possible for faster flow..

Jesse@JDLAutodesign · 04-19-2013, 05:15 PM

The length of the mufflers we had available at the time would not allow for any smooth flowing bends to make it straight. The bends would have had to be cheated and i didn't want that. It is just a prototype system that we did as a "one-off" on our car. When the time comes for a production system it will be different.

Tansey86 · 04-19-2013, 05:19 PM

Quote:

Originally Posted by Jesse@JDLAutodesign

The length of the mufflers we had available at the time would not allow for any smooth flowing bends to make it straight. The bends would have had to be cheated and i didn't want that. It is just a prototype system that we did as a "one-off" on our car. When the time comes for a production system it will be different.

Any more pictures of the exhaust on the car? Angles from the back and the side?
