Old 02-28-2013, 02:12 PM   #1
PhastekSport

PhastekSport's Avatar

Join Date: Sep 2012
Drives: 2013 Scion FR-S
Location: Houston, TX
Posts: 940
Thanks: 53
Thanked 696 Times in 284 Posts
Mentioned: 74 Post(s)
Tagged: 0 Thread(s)
Send a message via AIM to PhastekSport Send a message via Yahoo to PhastekSport
*PHASTEK* Perrin Tuned Vortech Supercharger Install Thread (3 Vehicles, 3 Kits)



I guess the ball is in our court. Here's where we will document all progress on the Vortech installs and the long term results. Expect updated for new pullies, tunes, general maintenance, etc.

2/28 - Supercharger arrives. Layout, photos, begin work after shop hours.



^V Nguyen (f1point4) laying out his kit for inventory/pictures.

3/1 - Continue work on shop car.

3/4 - My bday! I'll try to add some things as the day goes on. Lots of stuff to do in general. The community should get some good feedback of how this install goes from a "normal" person's perspective. On the average day at Phastek, I work on adding products, take some sales calls, and address any network/computer issues. All the installs are handled by techs.

The car feels great and the claimed gains were seen on the dyno (Dynojet 224x).

I do feel that anyone with a basic set of tools can get through the install. The DIY tutorial Victor is working on will layout all the tools we utilized. Having a buddy around helps out a lot. Set aside a good block of time though. Supercharger kits are not catback exhausts. They require more time!

First install observations:

As far as hiccups, there were just a few. We have 2 out of 3 installs down, so we're noting the minor issues which occurred on both installs first.

1) The first thing we noticed after using a dremel to grind down the boss on the alternator (as directed), was that the bracket needed a little off the back end shaved off. This was the only way we could get the bolt to thread. We're talking about a mm on the edge, tapered towards the center. Pictures will show this in detail.

2) We substituted out one of the hose clamps for the original throttle body clamp. Just keep you spare parts around during the install. The kit does reuse just a few parts.

3) Might need to recheck the windshield washer tank (new). There does appear to be a slight leak. Some thread tape might resolve this.

Not so much an issue as an observation. The intake pipe does touch the hood pad.

Our bumper has been taken off a few times. Just be careful. There are many DIY tutorials. I've made some modifications to get the gap down between the fender and the top of the bumper on the sides. I'll post those up later. This will help those who have damaged tabs.

This is a nice, clean install. We have known that since SEMA though :-).

Dyno right after install:

Before was with a Perrin headerback (no resonator, no cat). No other mods performance wise. The only thing that changed between that run was the tires (215s -> 245s).




Victor's Dyno Video:

[ame="http://www.youtube.com/watch?v=4UtgwC-SDM4"]PhastekPerformance.com - Perrin Tuned Vortech Supercharger Kit for FR-S / BRZ (Dyno Run) - YouTube[/ame]


Driving Observations:

The car really benefits from the added power. Drives like stock until you get into it. Nothing that really upsets the balance of the vehicle. A lot of commentary / video will be added after the track event @ TX2K13.

Expect this thread to grow a lot over the week. Right now it's just something I'm dumping my thoughts into so I don't forget.

Mileage before install: 8814

Pete's Install:

3/6 - Finished Pete's Install. He came a day later than he originally planned.





3/9 - Wasn't beating on the car too hard during the 0-60...

[ame="http://www.youtube.com/watch?v=kl4Pqn3n73A"]Phastek_FRS_Quick_Accel_test - YouTube[/ame]

Before / After Exhaust Sound Clips

[ame="http://www.youtube.com/watch?v=V4lFHfX7ex8"]PhastekPerformance.com - Exhaust Sound Before/After Perrin Tuned Vortech Supercharger Install - YouTube[/ame]


3/10 - Did revisit old private road for one higher speed run. Previously only taken up to redline in 5th which was around 130-131. Ran out of pavement and knew that it would take a lot more to exceed that speed in 6th. Same stretch with the kit, I claim 139, but the passenger says 140.

3/18 - First run results with a smaller pulley. Perrin map as well (specifically for the pulley).



3/22 Forgot to post new alternator tilt brackets..



The silver portion shows the area that is different.

These were sent overnight from Vortech.

Last edited by PhastekSport; 03-22-2013 at 09:16 AM.
PhastekSport is offline   Reply With Quote
The Following 6 Users Say Thank You to PhastekSport For This Useful Post:
Anthonytpt (04-03-2013), Brian@Vortech (02-28-2013), flippy (03-04-2013), norsamerican (02-28-2013), Pete (03-07-2013), sandman126 (02-28-2013)
Old 02-28-2013, 02:12 PM   #2
PhastekSport

PhastekSport's Avatar

Join Date: Sep 2012
Drives: 2013 Scion FR-S
Location: Houston, TX
Posts: 940
Thanks: 53
Thanked 696 Times in 284 Posts
Mentioned: 74 Post(s)
Tagged: 0 Thread(s)
Send a message via AIM to PhastekSport Send a message via Yahoo to PhastekSport
This has nothing to do with the thread other than that being a Vortech unit...



Just a little something to get everyone through their day.

Perrin will be getting the small pulley and map to us so there is definitely more to this story. We'll keep on pushing out numbers and media for a while.

By Thursday the vehicle will be at Texas World Speedway.

-------

3/14/2013

If you guys have the opportunity to track the FR-S/BRZ, I'd ask that you consider it! Lots of fun. I think I've found a new hobby. Yes, this was my first time EVER.

[ame="http://www.youtube.com/watch?v=hddJJ59P9jc"]PhastekPerformance.com - Perrin Tuned Vortech Supercharged FR-S @ Texas World Speedway (TX2k13) - YouTube[/ame]

Hotchkis Lowering Springs
Bridgestone Potenza S-04 Pole Positions (treadwear rating 280!)
Stock Brakes/Pads/Lines/Fluid

3/6 - New blowers installed Thursday.

"

For better or worse only honest numbers.

Temp: 71-75 degrees.

Winds:
Strong head wind. (err what do you call a head wind coming in at an angle? [roughly 45 degrees])

Wind Speed 7 mph
Max Wind Speed 20 mph
Max Gust Speed 25 mph

Track location:
Sealy, TX (Lonestar Motorsports Park - Hennessey)

Haven't drag raced since 2004 but these numbers were pretty consistent. Best trap speed and best ET shown.

Stock pulley on new blower. 3/4 tank of gas, some junk in the trunk, Perrin 92 map (map 3). Only have the Perrin headerback exhaust, 5zigen FN01R-C 17x8 (38 offset), and Bridgestone Pole Positions S04 - 245/40/17.

Dropping it at any RPMs it seems equals wheel hop. These runs reflect what had to be done to get no wheel hop. Any run with wheel hop was 14.3 or over.

For reference our tech's Pontiac G8 GT with cold air intake was running 13.94-14.3.

Sent from my wife using Tapatalk 2


EDIT: Found pic from 2004 @ drag strip in Fayetteville (outside Fort Bragg). That explains the haircut. We're just joking around... Obviously...

"

2nd run, no trac, wheel hop...

[ame="http://www.youtube.com/watch?feature=player_embedded&v=1tQUqK8mkkQ"]Scion FR-S Wheel Hop on Drag Strip - YouTube[/ame]

Semi Final Dyno Results



9/22 - Trying out other tunes before injectors + fuel pump and maybe e85.

Last edited by PhastekSport; 09-22-2013 at 12:18 PM.
PhastekSport is offline   Reply With Quote
The Following User Says Thank You to PhastekSport For This Useful Post:
mRdeMs83 (03-18-2013)
Old 02-28-2013, 02:12 PM   #3
F1point4
Photo Specialist

F1point4's Avatar

Join Date: Feb 2012
Drives: 2013 Toyota 86 DGM 6MT
Location: Texas
Posts: 1,152
Thanks: 587
Thanked 1,803 Times in 420 Posts
Mentioned: 94 Post(s)
Tagged: 0 Thread(s)
It's here............

It has been a long weekend. More information soon after we get some rest.

Feedback


More feedback to come after I drive it some more.

Just taking the numbers for our dyno charts, here are the gains we saw after installing the kit. The most important thing here is that all three of us got consistent gains. It goes a long way to show the manufacturing prowess of Vortech and the tuning abilities of Perrin! Installation was consistent too. The parts, fitment, etc was pretty consistent across all three vehicles.

20130306-ThreeKitsGains_Vortech by VictorN07, on Flickr



Comparison Dyno

After 170 mi it was time to do the comparison dyno. +50 whp and +25 TQ. Pretty much what was advertised.

Baseline:
Perrin Catted/Resonated Headerback
Stock Tune
Stock Intake/Filter

After:
Vortech Supercharger Kit
Perrin Stage 4 Tune



20130303-Comparison_Vortech by VictorN07, on Flickr



Videos

Parts Flyby
[ame="http://www.youtube.com/watch?v=WSTcXXUkYsY"]Toyota 86 Vortech Supercharger Kit Flyby - YouTube[/ame]



Chris's Car mid build. It's shaping up
[ame="http://www.youtube.com/watch?v=XqEkT6iPhu8"]Vortech Install Mid Build - YouTube[/ame]



Grinding down the boss to accommodate for the Vortech Alternator Tilt Bracket. This is explicitly written in the manual
[ame="http://www.youtube.com/watch?v=D-eKw-94HEs"]Vortech Supercharger Alternator Tilt Bracket Install Step - YouTube[/ame]



This is the first time we started my vehicle. Tuned by Perrin. Glorious moment
[ame="http://www.youtube.com/watch?v=0hTL6lcAq0c"]Toyota 86 Vortech Supercharger First Ignition - YouTube[/ame]



Dyno pull in fourth gear.
[ame="http://www.youtube.com/watch?v=aQE_eoyMZu0"]Toyota 86 Vortech Supercharger Pull (Tuned by Perrin Performance) - YouTube[/ame]



Unloaded throttle noise. Can hear the whistle from the kit. Good stuff
[ame="http://www.youtube.com/watch?v=mq3q8ZuvWHA"]Toyota 86 Vortech Supercharged Unloaded Blips - YouTube[/ame]



Launch control. He didn't go super quick cause we didn't know what was going on at the other end of the lot. The Perrin unresonated/uncatted headerback is bloody loud.
I stood next to Chris's car datalogging while he was doing dyno pulls. I think i lost a few points of hearing
[ame="http://www.youtube.com/watch?v=Xpx2G5CEphg"]Toyota 86 Vortech Supercharged Launch Control - YouTube[/ame]



Last one for today. My buddy and I was making goofs in the work parking garaged
[ame="http://www.youtube.com/watch?v=6EJmjBPC3fc"]Toyota 86 Vortech Supercharged Exhaust noise - YouTube[/ame]


"I love brakes" - Friends initial reaction to the added power
[ame="http://www.youtube.com/watch?v=ZIXBq-x-rsU"]"I Love Brakes" - YouTube[/ame]


Unscientific fun
[ame="http://www.youtube.com/watch?v=OMAelDtb2yE"]Cop Car! - YouTube[/ame]

Last edited by F1point4; 03-16-2013 at 01:05 AM.
F1point4 is offline   Reply With Quote
The Following 2 Users Say Thank You to F1point4 For This Useful Post:
Brian@Vortech (03-04-2013), djdnz (03-05-2013)
Old 02-28-2013, 02:13 PM   #4
F1point4
Photo Specialist

F1point4's Avatar

Join Date: Feb 2012
Drives: 2013 Toyota 86 DGM 6MT
Location: Texas
Posts: 1,152
Thanks: 587
Thanked 1,803 Times in 420 Posts
Mentioned: 94 Post(s)
Tagged: 0 Thread(s)
The Kit


20130228-VortechProductSpread-076 by VictorN07, on Flickr


20130228-VortechProductSpread-090 by VictorN07, on Flickr


20130228-VortechProductSpread-127 by VictorN07, on Flickr



Finally got a chance to visit the backlog of photos! Never too late to share a photo or two. @Chris@Phastek and I hope to show everyone what is included in the kit, so everybody knows what they are getting. @Brian@Vortech has already announced an upgrade to the kit, but it only affects the blower unit itself. Some feedback will be given on the difficulty of install on the part. Let's get to it.

Many Thanks to @Brian@Vortech, @PERRIN_Jeff for developing the kit. Also kudos to @PERRIN_Chris and Molly for excellent customer support. Been a treat working with all of them.



When the UPS Truck came, we knew it was time. Each large box was one kit. It does not include the 2.5K Bar MAP Sensor. That was a separate package

20130228-VortechProductSpread-011 by VictorN07, on Flickr

The Spread

20130228-VortechProductSpread-038 by VictorN07, on Flickr


20130228-VortechProductSpread-061 by VictorN07, on Flickr


20130228-VortechProductSpread-109 by VictorN07, on Flickr



Air pipes. The middle two pipes for the driver side. The two outside pipes fro the passenger side. There is a bag of hardware. It is very nicely organized. None of the parts/hardware on the table were labeled, so it was hard to do inventory based on the list included in the manual. It wasn't too much trouble, but labels would have made things much easier

20130228-VortechProductSpread-055 by VictorN07, on Flickr


Lots of clamps. Vortech sends extra which was really nice.

20130228-VortechProductSpread-064 by VictorN07, on Flickr

We get three bottles of lubricant. Each bottle is good for one change. The normal change interval is 7500 miles. There is a spout to make refilling the blower easy. What I like about this unit is that the fluid to lubricate the blower is self contained. No need to tap into the engine block for oil. Next to the fluid is silicone couplers used to connect the air tubes together. Last the airbox is behind.

20130228-VortechProductSpread-065 by VictorN07, on Flickr


20130228-VortechProductSpread-095 by VictorN07, on Flickr



This is the air filter provided for the blow off valve

20130228-VortechProductSpread-066 by VictorN07, on Flickr

Intercooler and mounting brackets

20130228-VortechProductSpread-074 by VictorN07, on Flickr

The airbox. A pre-oiled(?) K&N filter is provided

20130228-VortechProductSpread-075 by VictorN07, on Flickr

Blowoff valve, **EDIT** One Idler Pulley, and brackets

20130228-VortechProductSpread-077 by VictorN07, on Flickr

One of the things we had to do was extend the MAF Sensor wire. The stock MAF Sensor is at the exit of the stock air intake box. The MAF Sensor in the vortech kit now sits behind the passenger side turn signal. It comes with all the wire and loom so you can solder and protect everything. Your own electrical tape is required to make it look "OEM". To the left of this is the 2.5K Bar Manifold Air Pressure sensor. It plugs into the intake manifold under the Boxer cover. This MAP sensor is not included in the normal kit.

20130228-VortechProductSpread-081 by VictorN07, on Flickr

These are assorted clamps and bits to hook up the blowoff valve, poipes, etc. They also included a one way check valve for the PCV system so the charged air doesn't get pushed into the crankcase by accident! Around this is the extended belt. With the blower mounted in place, there is about 2" between the motor and the blower to slip on the belt. Difficult but not impossible.

20130228-VortechProductSpread-082 by VictorN07, on Flickr


20130228-VortechProductSpread-108 by VictorN07, on Flickr

At the top you can see the stainless steel drain hose for the blower. It reaches down past the metal skid pan. Should be cake to drain the fluid.
Below these are brackets to mount the blower and spacers for the new pulley. The blower holds on the two new idler pulleys. The lower right bracket is to raise the alternator. As mentioned already this is the old bracket which causes fitment issues. A new bracket has been issued already. Talked to Brian and Mike at Vortech and they have been nothing but good to me.

20130228-VortechProductSpread-083 by VictorN07, on Flickr


The blower @Brian@Vortech has already announced an upgrade to the kit. All customers should be getting their units upgraded soon. From my discussions with Brian a new higher flow impeller will be installed as well as a slightly smaller pulley. Reports that it will make 9 lbs of boost (up from 7) and is good for close to 300 flywheel HP on 91 pump gas. We'll be sure to test it out once the units come back.

20130228-VortechProductSpread-085 by VictorN07, on Flickr


This is the stock pulley (under the grey cap). The cap is there for warranty purposes

20130228-VortechProductSpread-087 by VictorN07, on Flickr

Team PerTech

20130228-VortechProductSpread-097 by VictorN07, on Flickr

I believe the kit is mass produced. This is an example of the welds on the pipe. Not the greatest quality IMO, but since its for air it will be okay.


20130228-VortechProductSpread-149 by VictorN07, on Flickr






Fun stuff

20130228-VortechProductSpread-120 by VictorN07, on Flickr

The Phastek Performance Crew checking out the goods

20130228-VortechProductSpread-126 by VictorN07, on Flickr




Other Feedback


Avid car enthusiast Princeton Wong covered our install on his blog VicariousGear! Check out his thoughts on the link after the break!

http://vicariousgear.com/2013/03/15/...-for-the-fr-s/

Quote:
....My short trip back to Houston just happened to coincide with the arrival of the first couple Vortech Supercharger kits for the ZN6/ZC6 platforms. Being an early adopter, my cousin Victor invited me out to Phastek Performance to check out the pieces and help with the wrenching. Being a grease monkey at heart combined with my love of new tech, I couldn’t resist. It is always great to see how different garages are set up as well. I arrived at Phastek in the middle of the first install which was moving slowly but surely. Things were being double and triple checked since these were some of the initial test kits. A few pieces appeared to have overly tight tolerances to moving belts but everything worked out in the end.....
Resized pictures to not break the tables


Me doing my best Jeff Perrin Impression
Name:  pcw_8913.jpg
Views: 6243
Size:  241.8 KB

Chris and I reinstalling the bumper
Name:  pcw_8920.jpg
Views: 6214
Size:  229.6 KB

Last edited by F1point4; 03-27-2013 at 09:59 AM.
F1point4 is offline   Reply With Quote
The Following User Says Thank You to F1point4 For This Useful Post:
Anthonytpt (04-03-2013)
Old 02-28-2013, 02:13 PM   #5
Pete
Senior Member

Pete's Avatar

Join Date: Aug 2012
Drives: 22 BRZ
Location: Houston, TX
Posts: 615
Thanks: 1,341
Thanked 478 Times in 230 Posts
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)



Last edited by Pete; 03-07-2013 at 11:05 AM.
Pete is offline   Reply With Quote
Old 02-28-2013, 02:14 PM   #6
Pete
Senior Member

Pete's Avatar

Join Date: Aug 2012
Drives: 22 BRZ
Location: Houston, TX
Posts: 615
Thanks: 1,341
Thanked 478 Times in 230 Posts
Mentioned: 15 Post(s)
Tagged: 0 Thread(s)
again
Pete is offline   Reply With Quote
Old 02-28-2013, 05:44 PM   #7
Do Boy
Turbo FR-S

Do Boy's Avatar

Join Date: May 2011
Drives: 2013 Scion FR-S
Location: Pearland,TX
Posts: 680
Thanks: 227
Thanked 269 Times in 150 Posts
Mentioned: 12 Post(s)
Tagged: 0 Thread(s)
Garage
Send a message via ICQ to Do Boy Send a message via AIM to Do Boy Send a message via MSN to Do Boy Send a message via Yahoo to Do Boy
Nice can't wait to see it
Do Boy is offline   Reply With Quote
Old 02-28-2013, 06:03 PM   #8
DBacon1052
Senior Member

DBacon1052's Avatar

Join Date: Jul 2012
Drives: Argento FR-S
Location: SoCal: Aliso Viejo
Posts: 569
Thanks: 178
Thanked 156 Times in 94 Posts
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Garage
Awesome! The kit is great. Cant wait to see the install.
DBacon1052 is offline   Reply With Quote
Old 02-28-2013, 09:05 PM   #9
Coheed
Senior Member

Coheed's Avatar

Join Date: Jun 2012
Drives: DGM BRZ Limited
Location: Seattle
Posts: 813
Thanks: 209
Thanked 225 Times in 157 Posts
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
I gotta say, I am eager for results as well.
Coheed is offline   Reply With Quote
Old 03-01-2013, 10:21 AM   #10
F1point4
Photo Specialist

F1point4's Avatar

Join Date: Feb 2012
Drives: 2013 Toyota 86 DGM 6MT
Location: Texas
Posts: 1,152
Thanks: 587
Thanked 1,803 Times in 420 Posts
Mentioned: 94 Post(s)
Tagged: 0 Thread(s)
Cell phone pic from earlier this morning. Chris's install is shaping up. So many thoughts to share
Attached Images

F1point4 is offline   Reply With Quote
Old 03-01-2013, 10:25 AM   #11
norsamerican
Senior Member

norsamerican's Avatar

Join Date: Jan 2013
Drives: WRB BRZ
Location: Houston
Posts: 539
Thanks: 101
Thanked 233 Times in 112 Posts
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
NICE!
norsamerican is offline   Reply With Quote
Old 03-01-2013, 10:30 AM   #12
F1point4
Photo Specialist

F1point4's Avatar

Join Date: Feb 2012
Drives: 2013 Toyota 86 DGM 6MT
Location: Texas
Posts: 1,152
Thanks: 587
Thanked 1,803 Times in 420 Posts
Mentioned: 94 Post(s)
Tagged: 0 Thread(s)
Can't wait to write up this DIY. It should answer most people's questions about the kit and its installation
F1point4 is offline   Reply With Quote
The Following 2 Users Say Thank You to F1point4 For This Useful Post:
Amadeus (03-01-2013), ATL BRZ (03-01-2013)
Old 03-01-2013, 10:31 AM   #13
norsamerican
Senior Member

norsamerican's Avatar

Join Date: Jan 2013
Drives: WRB BRZ
Location: Houston
Posts: 539
Thanks: 101
Thanked 233 Times in 112 Posts
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
i cant wait to see it!

-Erik
norsamerican is offline   Reply With Quote
Old 03-01-2013, 12:46 PM   #14
PERRIN_Chris
Senior Member

Join Date: Apr 2012
Drives: 2014 Subaru BRZ
Location: Hillsboro, Oregon
Posts: 770
Thanks: 450
Thanked 536 Times in 316 Posts
Mentioned: 137 Post(s)
Tagged: 2 Thread(s)
Garage
Send a message via AIM to PERRIN_Chris
Quote:
Originally Posted by F1point4 View Post
Cell phone pic from earlier this morning. Chris's install is shaping up. So many thoughts to share
This would be a perfect "make a caption" pics!
PERRIN_Chris is offline   Reply With Quote

Reply

Tags
ft86, perrin, phastek, supercharger, vortech

Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off

Forum Jump

Similar Threads
Thread Thread Starter Forum Replies Last Post
Visconti Tuning Vortech STG1 & STG1+ Supercharger Kits! Visconti Forced Induction 67 04-03-2013 03:56 PM
Vortech Supercharger Kits @Pure Automotive Performance Pure Automotive Forced Induction 25 01-15-2013 11:48 PM


All times are GMT -4. The time now is 11:12 PM.


Powered by vBulletin® Version 3.8.11
Copyright ©2000 - 2024, vBulletin Solutions Inc.
User Alert System provided by Advanced User Tagging v3.3.0 (Lite) - vBulletin Mods & Addons Copyright © 2024 DragonByte Technologies Ltd.

Garage vBulletin Plugins by Drive Thru Online, Inc.
